Product Details:
|
| Name: | Carbon Steel Elbow | Radius: | 90 Degree |
|---|---|---|---|
| Size: | 1/2"-48" | Standard: | ASTM JIS,GOST DIN BS |
| Certificate: | PED ISO API | PACKAGE: | Wooden Box Or Case |
| Highlight: | Q345 Carbon Steel Elbow,B16.9 Long Radius butt weld elbow,Q345 schedule 40 weld elbows |
||
Carbon Steel Elbow bend SCH40 ASTM B16.9 90 Degree Long Radius Elbow Butt Welding Pipe Fittings
Three-way hot press forming is to flatten the tube blank larger than the diameter of the three-way to the size of the diameter of the three-way, and open a hole in the part of the drawn branch pipe; The die for drawing the branch pipe is loaded into it; the tube blank is radially compressed under the action of pressure. During the process of radial compression, the metal flows in the direction of the branch pipe and forms the branch pipe under the stretching of the die. The whole process is formed by the radial compression of the tube blank and the stretching process of the branch pipe. Different from the hydraulic bulging tee, the metal of the hot-pressed tee branch pipe is compensated by the radial movement of the tube blank, so it is also called the radial compensation process.
| Name | ELBOW |
| Grade | Q345, Q235, 20#, 10#, Q195 |
| Usage | Construction Structure, Building, Transportation, For Liquid Delivery, chemical industry |
| Outside Diameter | 6 - 760 mm, 10 - 1000 mm, 20 - 457 mm, 406 - 1420 mm, 33.4 - 762 mm |
| Main Material | A234-WPB；A420-WPL3/ WPL6；WP5；WP9；WP11；WP22；NACE MR-0175
API5L-X42/46/52/56/60/65/70/80(NS/MS) A403-WP304/L；WP316/L；S31803; 2205 |
| Outside diameter | 6 - 760 mm, 10 - 1000 mm, 20 - 457 mm, 406 - 1420 mm, 33.4 - 762 mm |
| Main Standard | ANSI , DIN2605, JIS, GB, GOST17375, GOST 30753, EN10253, BS |
| Surface Treatment | Galvanized, bare, oiled, oiled coating/varnish coating/anti-rust coating/galvanized, anti-corrosion coating as request |
| Producing technique | Forged, Casting, Heat treatment , welding, Seamless |
| Inspection | Chemical Elements, Mechanical Property, Metallographic Test, Heat Treatment, Ultrasonic Test, Penetration Test, Magnetic Powder Test, X-Ray Test, Hydraulic Pressure Test, Blasting Experiment |
| End protector | Plastic Pipe Cap, BE/Beveled Ends, Reqeust, PE/Plain Ends |
Cangzhou Authentic Pipe fitting Manufacturing Co., Ltd., which specialize in the manufacture and export of Pipe fittings for 20 years.
Our products is covering ELBOW,FLANGE,TEE,REDUCER,CAP and steel pipes, our material is including carbon steel , stainless steel,
alloy steel with black painting and am anti-rust oil.We also have ISO, PED and API certificates to make sure our quality, our goods is sold
to Europe, Southeast ,East Europe and many other countries.
If you are interested in our products ,please give me your specific and formal inquiry. We will supply best quality and competitive price.
Our products sells well in domestic markets, also largely export to overseas markets such as Korea, Singapore, Malaysia, Russia, Germany, Spain, Arabia, South Africa ect countries and areas.
